Machine Tap HSS-E BSF Blind-Trough Hole DIN 376 C Hepyc 2142


Machine tap HSS-E, BSF, according to standard DIN 376, form C. Brand Hepyc with reference 2142.



For internal threading of BSF thread BS 24 with right direction of rotation in blind and trough holes, in steel, cast iron and non-ferrous metal.

specifications

Brand Hepyc
Reference 2142
Cutting material HSS-E
Coating -
Standard DIN 376
Form C
Helix -
Cutting direction Right-hand
Thread BSF BS 24
Tolerance -
Shank Straight with square

material

articles

Article code ø x G inch L x l mm ◘ x d mm
 21420071600 7/16 x 18 90 x 22 6,2 x 8,0
21420010200 1/2 x 16 100 x 22 7,0 x 9,0
21420091600 9/16 x 16 100 x 22 9,0 x 11,0
21420050800 5/8 x 14 100 x 22 9,0 x 12,0
21420030400 3/4 x 12 110 x 25 11,0 x 14,0
21420070800 7/8 x 11 125 x 25 14,5 x 18,0
21420100000 1" x 10 140 x 28 14,5 x 18,0
