End Mill Solid Carbide AlCrN DIN 6527 L 4F/Corner Radius Hepyc 3178

End mill solid carbide, AlCrN-coated, according to standard DIN 6527 L, type N-V, 4 flutes, with straight shank DIN 6535 HA, with corner radius. Brand Hepyc with reference 3178.

For milling in steel, stainless steel, cast iron, non-ferrous metal, superalloys and hard materials.

specifications

Brand	Hepyc
Reference	3178
Cutting material	Carbide
Coating	AlCrN
Standard	DIN 6527 L
Type	N-V
Cutting edges	4 flutes
Point	Flat - Corner radius
Helix	30°
Cutting direction	Right-hand
Shank	DIN 6535 HA

material

Articles

Article code	ø mm x r	d mm	L x l mm
31780006005	6,0 x r 0,5	6	57 x 13
31780006010	6,0 x r 1,0	6	57 x 13
31780008005	8,0 x r 0,5	8	63 x 19
31780008010	8,0 x r 1,0	8	36 x 19
31780010005	10,0 x r 0,5	10	72 x 22
31780010010	10,0 x r 1,0	10	72 x 22
31780010020	10,0 x r 2,0	10	72 x 22
31780012005	12,0 x r 0,5	12	83 x 26
31780012010	12,0 x r 1,0	12	83 x 26
31780012020	12,0 x r 2 ,0	12	83 x 26
31780016005	16,0 x r 0,5	16	92 x 32
31780016010	16,0 x r 1,0	16	92 x 32
31780016020	16,0 x r 2,0	16	92 x 32
