3-Side & Face Milling Cutter HSS-E DIN 885 A Hepyc 3161


3-side and face milling cutter HSS-E, according to standard DIN 885, type A, staggered teeth, with bore with longitudinal groove. Brand Hepyc with reference 3161.



For grooving or cutting in steel, stainless steel, cast iron, non-ferrous metal and superalloys.

specifications

Brand Hepyc
Reference 3161
Cutting material HSS-E
Coating -
Standard DIN 885
Type A
Cutting edges 18 - 24 - Staggered teeth
Point Face - 3-side
Helix -
Cutting direction Right-hand
Shank Bore with longitudinal groove

material

Articles

Article code ø mm Bore mm e mm Z
31610063004 63,0 22 4 18
31610063005 63,0 22 5 18
31610063006 63,0 22 6 18
31610063008 63,0 22 8 18
31610063010 63,0 22 10 18
31610080004 80,0 27 4 20
31610080005 80,0 27 5 20
31610080006 80,0 27 6 20
31610080008 80,0 27 8 20
31610080010 80,0 27 10 20
31610080012 80,0 27 12 20
31610100006 100,0 32 6 24
31610100008 100,0 32 8 24
31610100010 100,0 32 10 24
31610100012 100,0 32 12 24
31610100014 100,0 32 14 24
31610125006 125,0 32 6 24
31610125008 125,0 32 8 24
31610125010 125,0 32 10 24
31610125012 125,0 32 12 24
31610125014 125,0 32 14 24
31610125016 125,0 32 16 24
Back
