Twist Drill Bit Long HSS DIN 340 N Hepyc 1112


Twist drill bit long HSS, according to standard DIN 340, type N, with straight shank. Brand Hepyc with reference 1112.

Available in standard packaging per 10/5/4 pieces or per piece.



For drilling holes in steel, cast iron and non-ferrous metal.

specifications

Brand Hepyc
Reference 1112
Cutting material HSS
Coating -
Standard DIN 340
Type N
Point 118°
Helix 30°
Cutting direction Right-hand
Shank Straight

material

Articles

Article code ø mm L x l mm
11120000100 1,00 56 x 33
11120000110 1,10 60 x 37
11120000120 1,20 65 x 41
11120000125 1,25 65 x 41
11120000130 1,30 65 x 41
11120000140 1,40 70 x 45
11120000150 1,50 70 x 45
11120000160 1,60 76 x 50
11120000170 1,70 76 x 50
11120000175 1,75 80 x 53
11120000180 1,80 80 x 53
11120000190 1,90 80 x 53
11120000200 2,00 85 x 56
11120000210 2,10 85 x 56
11120000220 2,20 85 x 56
11120000225 2,25 90 x 59
11120000230 2,30 90 x 59
11120000240 2,40 95 x 62
11120000250 2,50 95 x 62
11120000260 2,60 100 x 66
11120000270 2,70 100 x 66
11120000275 2,75 100 x 66
11120000280 2,80 100 x 66
11120000290 2,90 100 x 66
11120000300 3,00 100 x 66
11120000310 3,10 106 x 69
11120000320 3,20 106 x 69
11120000325 3,25 106 x 69
11120000330 3,30 106 x 69
11120000340 3,40 112 x 73
11120000350 3,50 112 x 73
11120000360 3,60 112 x 73
11120000370 3,70 112 x 73
11120000375 3,75 112 x 73
11120000380 3,80 119 x 78
11120000390 3,90 119 x 78
11120000400 4,00 119 x 78
11120000410 4,10 119 x 78
11120000420 4,20 119 x 78
11120000425 4,25 119 x 78
11120000430 4,30 126 x 82
11120000440 4,40 126 x 82
11120000450 4,50 126 x 82
11120000460 4,60 126 x 82
11120000470 4,70 126 x 82
11120000475 4,75 126 x 82
11120000480 4,80 132 x 87
11120000490 4,90 132 x 87
11120000500 5,00 132 x 87
11120000510 5,10 132 x 87
11120000520 5,20 132 x 87
11120000525 5,25 132 x 87
11120000530 5,30 132 x 87
11120000540 5,40 139 x 91
11120000550 5,50 139 x 91
11120000560 5,60 139 x 91
11120000570 5,70 139 x 91
11120000575 5,75 139 x 91
11120000580 5,80 139 x 91
11120000590 5,90 139 x 91
11120000600 6,00 139 x 91
11120000610 6,10 148 x 97
11120000620 6,20 148 x 97
11120000625 6,25 148 x 97
11120000630 6,30 148 x 97
11120000640 6,40 148 x 97
11120000650 6,50 148 x 97
11120000660 6,60 148 x 97
11120000670 6,70 148 x 97
11120000675 6,75 156 x 102
11120000680 6,80 156 x 102
11120000690 6,90 156 x 102
11120000700 7,00 156 x 102
11120000710 7,10 156 x 102
11120000720 7,20 156 x 102
11120000725 7,25 156 x 102
11120000730 7,30 156 x 102
11120000740 7,40 156 x 102
11120000750 7,50 156 x 102
11120000760 7,60 165 x 109
11120000770 7,70 165 x 109
11120000775 7,75 165 x 109
11120000780 7,80 165 x 109
11120000790 7,90 165 x 109
11120000800 8,00 165 x 109
11120000810 8,10 165 x 109
11120000820 8,20 165 x 109
11120000825 8,25 165 x 109
11120000830 8,30 165 x 109
11120000840 8,40 165 x 109
11120000850 8,50 165 x 109
11120000875 8,75 175 x 115
11120000880 8,80 175 x 115
11120000890 8,90 175 x 115
11120000900 9,00 175 x 115
11120000925 9,25 175 x 115
11120000930 9,30 175 x 115
11120000940 9,40 175 x 115
11120000950 9,50 175 x 115
11120000970 9,70 184 x 121
11120000975 9,75 184 x 121
11120000990 9,90 184 x 121
11120001000 10,00 184 x 121
11120001025 10,25 184 x 121
11120001030 10,30 184 x 121
11120001040 10,40 184 x 121
11120001050 10,50 184 x 121
11120001075 10,75 195 x 128
11120001100 11,00 195 x 128
11120001110 11,10 195 x 128
11120001120 11,20 195 x 128
11120001125 11,25 195 x 128
11120001150 11,50 195 x 128
11120001175 11,75 195 x 128
11120001200 12,00 205 x 134
11120001225 12,25 205 x 134
11120001250 12,50 205 x 134
11120001275 12,75 205 x 134
11120001300 13,00 205 x 134
11120001325 13,25 214 x 140
11120001350 13,50 214 x 140
11120001375 13,75 214 x 140
11120001400 14,00 214 x 140
11120001450 14,50 220 x 144
11120001500 15,00 220 x 144
11120001550 15,50 227 x 149
11120001600 16,00 227 x 149
11120001650 16,50 235 x 154
11120001700 17,00 235 x 154
11120001750 17,50 241 x 158
11120001800 18,00 241 x 158
11120001850 18,50 247 x 162
11120001900 19,00 247 x 162
11120001950 19,50 254 x 166
11120002000 20,00 254 x 166
