Twist Drill Bit Left-hand HSS DIN 338 N Hepyc 1101/1

Twist drill bit left-hand, HSS, according to standard DIN 338, type N, with straight shank. Brand Hepyc with reference 1101/1.
Available in standard packaging per 10/5/4 pieces or per piece.

For drilling holes in steel, cast iron and non-ferrous metal.

specifications

Brand	Hepyc
Reference	1101/1
Cutting material	HSS
Coating	-
Standard	DIN 338
Type	N
Point	118°
Helix	30°
Cutting direction	Left-hand
Shank	Straight

material

Articles

Article code	ø mm	L x l mm
11011000200	2,00	49 x 24
11011000225	2,25	53 x 27
11011000250	2,50	57 x 30
11011000275	2,75	61 x 33
11011000300	3,00	61 x 33
11011000325	3,25	65 x 36
11011000350	3,50	70 x 39
11011000375	3,75	70 x 39
11011000400	4,00	75 x 43
11011000450	4,50	80 x 47
11011000500	5,00	86 x 52
11011000525	5,25	86 x 52
11011000550	5,50	93 x 57
11011000600	6,00	93 x 57
11011000650	6,50	101 x 63
11011000700	7,00	109 x 69
11011000750	7,50	109 x 69
11011000800	8,00	117 x 75
11011000850	8,50	117 x 75
11011000900	9,00	125 x 81
11011000950	9,50	125 x 81
11011001000	10,00	133 x 87
11011001050	10,50	133 x 87
11011001100	11,00	142 x 94
11011001150	11,50	142 x 94
11011001200	12,00	151 x 101
