Twist Drill Bit HSS Widia DIN 338 N Hepyc 1110


Twist drill bit HSS, according to standard DIN 338, type N, with straight shank, equiped with Widia point. Brand Hepyc with reference 1110.



For drilling holes in steel, cast iron and non-ferrous metal.

specifications

Brand Hepyc
Reference 1110
Cutting material HSS - Widia
Coating -
Standard DIN 338
Type N
Point 118°
Helix 30°
Cutting direction Right-hand
Shank Straight

material

Articles

Article code ø mm L x l mm
11100000150 1,50 40 x 18
11100000200 2,00 49 x 24
11100000250 2,50 57 x 30
11100000300 3,00 61 x 33
11100000350 3,50 70 x 39
11100000400 4,00 75 x 43
11100000450 4,50 80 x 47
11100000500 5,00 86 x 52
11100000550 5,50 93 x 57
11100000600 6,00 93 x 57
11100000650 6,50 101 x 63
11100000700 7,00 109 x 69
11100000750 7,50 109 x 69
11100000800 8,00 117 x 75
11100000850 8,50 117 x 75
11100000900 9,00 125 x 81
11100000950 9,50 125 x 81
11100001000 10,00 133 x 87
11100001050 10,50 133 x 87
11100001100 11,00 142 x 97
11100001200 12,00 151 x 101
11100001300 13,00 151 x 101
11100001400 14,00 160 x 108
11100001500 15,00 169 x 114
11100001600 16,00 178 x 120
11100001700 17,00 184 x 125
11100001800 18,00 191 x 130
11100001900 19,00 198 x 135
11100002000 20,00 205 x 140
