Twist Drill Bit Inch HSS DIN 345 N Hepyc 1121/9

Twist drill bit inch HSS, according to standard DIN 345, type N, with morse taper shank, equiped with split point top corner. Brand Hepyc with reference 1121/9.

For drilling holes in steel, cast iron and non-ferrous metal, inch-size.

specifications

Brand	Hepyc
Reference	1121/9
Cutting material	HSS
Coating	-
Standard	DIN 345
Type	N
Point	118° - Split point
Helix	30°
Cutting direction	Right-hand
Shank	Morse taper

material

articles

Article code	ø inch	L x l mm
11219000102	1/2	182 x 101
11219003364	33/64	182 x 101
11219001732	17/32	189 x 108
11219003564	35/64	189 x 108
11219000916	9/16	212 x 114
11219003764	37/64	212 x 114
11219001932	19/32	218 x 120
11219003964	39/64	218 x 120
11219000508	5/8	218 x 120
11219004164	41/64	223 x 125
11219001116	11/16	223 x 125
11219004564	45/64	223 x 125
11219002332	23/32	233 x 135
11219004764	47/64	233 x 135
11219000304	3/4	238 x 140
11219004964	49/64	238 x 140
11219002532	25/32	238 x 140
11219005164	51/64	243 x 145
11219001316	13/16	243 x 145
11219005364	53/64	143 x 145
11219002732	27/32	248 x 150
11219005564	55/64	248 x 150
11219000708	7/8	248 x 150
11219005764	57/64	253 x 155
11219002932	29/32	253 x 155
11219005964	59/64	276 x 155
11219001516	15/16	281 x 160
11219006164	61/64	281 x 160
11219003132	31/32	281 x 160
11219006364	63/64	286 x 160
11219010000	1"	291 x 170
11219010116	1.1/16"	291 x 170
11219010108	1.1/8"	296 x 175
11219010532	1.5/32"	296 x 175
11219010316	1.3/16"	301 x 180
11219010732	1.7/32"	301 x 180
11219010104	1.1/4"	306 x 185
11219010932	1.9/32"	334 x 185
11219010516	1.5/16"	334 x 185
11219011132	1.11/32"	339 x 190
11219010308	1.3/8"	339 x 190
11219011332	1.13/32"	344 x 195
11219010716	1.7/16"	344 x 195
11219010102	1.1/2"	349 x 200
11219010916	1.9/16"	349 x 200
11219010508	1.5/8"	349 x 200
11219011116	1.11/16"	359 x 210
11219010304	1.3/4"	359 x 210
11219020000	2"	374 x 225
