Adjustable Hand Reamer HSS A With Guide Hepyc 4111


Adjustable hand reamer HSS, form A, with guide, with straight shank with square. Brand Hepyc with reference 4111.



For reaming holes in steel, cast iron and non-ferrous metal.

specifications

Brand Hepyc
Reference 4111
Cutting material -
Coating -
Standard -
Form A
Helix -
Tolerance -
Shank Straight with square

material

Articles

Article code ø mm d mm L x l mm
41110080090 8,00 - 9,00 4,5 175 x 35
41110090100 9,00 - 10,00 5,5 185 x 35
41110100110 10,00 - 11,00 5,9 195 x 40
41110110120 11,00 - 12,00 6,5 200 x 41
41110120135 12,00 - 13,50 7,5 220 x 44
41110135155 13,50 - 15,50 8,0 243 x 53
41110155180 15,50 - 18,00 9,5 274 x 61
41110180210 18,00 - 21,00 12,0 300 x 66
41110210240 21,00 - 24,00 13,5 320 x 70
41110240275 24,00 - 27,50 15,0 350 x 83
41110275315 27,50 - 31,50 18,5 385 x 88
41110315370 31,50 - 37,00 21,0 424 x 91
41110370450 37,00 - 45,00 25,0 490 x 25
41110450550 45,00 - 55,00 32,0 600 x 128
41110550670 55,00 - 67,00 42,0 740 x 150
41110670800 67,00 - 80,00 45,0 830 x 170
